7427933
SnapVerified
Ferrite Bead, Flat Wire, 39Ohm, 14A Rohs Compliant: Yes |Wurth Elektronik 7427933
Availability: Out of Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 7427933 by Wurth Elektronik and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 7427933
| Part Name | 7427933 |
| Manufacturer | Wurth Electronics |
| Product Series Size | 3029 |
| Division | Passive Components, Power Modules, Optoelectronics |
| Article Description Long | Size 3029; Z @ 25 MHz = 23 Ω; Z @ 100 MHz = 39 Ω; IR = 14 A; RDC = 0.6 mΩ |
| Weight | 0.08 |
| Product Family | Ferrites For PCB Assembly |
| Ro Hs Approval | Compliant |
| Rated Current (A) | 14 |
| Spq | 1000 |
| Current Revision (A) | 2.0.0 |
| Packaging Type | 7''Reel |
| Height | 2.41 mm |
| Reach Approval | Conform or declared |
| Width | 2.9 mm |
| Length | 3.1 mm |
| Product Unit | eiSos |
| Product Group Description | EMC Components |
| RoHS | True |
| Life Cycle Status | New at Mouser |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
