LT1118CST-5#PBF
Linear Voltage Regulator IC; Voltage Regulator Type:LDO Linear; Input Voltage Primary Max:15V; Output Voltage Max:5V; Output Current Max:800mA; Dropout Voltage, Vdo:1V; No. of Outputs:1; Supply Voltage Min:3V; Supply Voltage Max:15V ;RoHS Compliant: Yes
Availability: In Stock
Package Type: SOT-223-3
CAD Models: Footprint
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the LT1118CST-5#PBF by Analog Devices and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
